| Specifications |
| Coating Thickness |
Variable from 6 to 14Microns |
| Maximum coating material weight |
400gsm |
| Coating technology |
UV coating 100% curable, primer coating, water-based liquid coating, Heater |
| Coater/Curing unit |
Integrated one unit with concealed conveyor path. |
| Speed |
30 ~ 35 meter per minute |
| Coating size(width) |
17R(17”, 432mm), 20R(20”, 508mm), 24R(24”, 610mm), 36R(36”, 914mm) |
| Coating varnish |
Matte, Luster |
| Power consumption |
10 ~ 20Kw |
| Power Supply |
210 ~ 240V, 50/60Hz, Single Phase or 380 ~ 415V, 50/60Hz, Three Phase. |
| Dimensions(L x W x H mm) |
17R(1350 x 780 x 1110), 20R(1350 x 850 x 1110) 24R(1350 x 1030 x 1110),
36R(1620 x 1330 x 1190) |
| Options |
Automatic deep pile feeder, Automatic stacker |
| Auto Feeder Stack Pile Height |
Max. 650mm |
| Auto Stacker Pile Height |
Max.540mm |
|
|
|
|
|
|
