| Web width |
Max. 360mm Min. 200mm |
| Unwind and Rewind Roll Diameter |
Max. 700mm |
| Core Diameter |
3"(76mm) |
| Dimensions(L x W x H) |
2305 x 1445 x 1920mm |
| Power Supply |
200~240V, 50/60Hz 3P or
380~415V, 50/60Hz 3P |
| Power Consumption |
14.52 KW |
| Coating Technology |
UV / Primer / Water-Based Liquid Coating |
| Coating Processing |
Glossy, Matte, Primer |
|
| Coating Substrate |
Paper and Film |
| Coating Pattern |
Smooth |
| Mechanical Design Speed |
100 meter /min |
| Coating Sp |
Variable according to web material and types of coating varn |
| Corona Unit |
Ceramic generating |
| Auto web-guide system equipped |
| Auto tension control system equipped |
| |
|
|
