| Binding size(L x W) |
Max. 14”x 15”(355x380mm),
Min. 6”x6”(180x150mm) |
| Signature thickness |
print – 120~400gsm, cardboard – 350~1500gsm |
| Binding thickness |
1 ~ 50mm |
| Designed Binding speed |
Max.100 signatures/min |
| Operation Binding speed |
Max.60 signatures/min |
| Type of glue |
Water-based glue. |
| Gluing system |
Roller gluing system |
| Glue supply |
Automatic pump supply with stop sensor. |
| Operation display |
7” full color touch screen |
| Signature feeder |
Automatic dual feeder |
| Power |
380~415/200~240 VAC 50 or 60Hz, 3Phase, 3500W |
| Dimension(L x W X H) |
1100 x 1000 x 1600mm |
| Net weight |
600kgs |
| Gross weight |
About 700kgs |
| Automatic job size setting |
|
