| Specifications |
| Application |
Digital prints, Offset prints, Photo prints, etc. |
| Speed |
Max. 25m/min. Operation 15/min.(2,500sheets/hour – A3) |
| Laminating technology |
Thermal laminating |
| Paper size(W x L) |
Max. 520 x 720mm, Min. 210 x 250mm |
| Substrate weight |
115 ~ 350gsm |
| Applicable film |
OPP, PET, Nylon |
| X-Unit |
Toner and Wax treatment device |
| Feeder pile height |
400mm |
| Film roll size |
Max. 350mm |
| Dimensions(L x W x H mm) |
2340 x 920 x 1250mm |
| Power consumption |
7Kw, 30AMP |
| Power Supply |
210 ~ 240V, Single Phase, 50/60Hz |
| Option |
Jogging Table, Perforation, Slitting, Auto Stacker |
|
|
|
|
|
|
