| Coating technology |
Piezo Inkjet printing technology |
| Printing width |
Max. 350mm or Max. 500mm |
| Working format Max |
W 520 x L 720mm |
| Working format Min |
W 210 x L 297mm |
| Paper thickness |
120 ~ 600gsm |
| Type of varnish |
UV clear Ink specified by Kisun |
| Auto feeder |
max. 650mm deep pile |
|
| Stacker |
max. 540mm deep pile |
| Dryer |
100% curable UV dryer |
| Speed |
0.45meter/sec at 360Dpi |
| Power supply |
380V, 60Hz, 3phase |
| Power consumption |
10KW |
| Dimension |
L 6,000 x W 900 x H 1,100mm |
| Weight |
abt. 10,000kgs |
|
